Epson SureColor P9570 Standard Edition Printer

Description

Product Highlights

Epson SureColor P9570 44-Inch Wide-Format Printer: overview

The Epson SureColor P9570 is a 44-inch, 12-color pigment printer for large fine art, photographic and graphics output. Its 2.6-inch PrecisionCore MicroTFP printhead has 9,600 nozzles across 12 channels and prints at up to 2400 x 1200 dpi with 3.5 pl droplets. Epson lists print speeds of 2:02 (Black Enhance Overcoat off) and 4:04 (on) for a 23.4 x 33.1 inch print, and states that the printer is up to 2.4 times faster than the previous generation.

It uses UltraChrome PRO12 pigment ink: Cyan, Light Cyan, Vivid Magenta, Vivid Light Magenta, Yellow, Gray, Light Gray, Orange, Green, Photo Black, Matte Black and Violet. Epson reports up to 99 percent coverage of the PANTONE FORMULA GUIDE solid-coated palette (see Epson’s footnotes), plus Black Enhance Overcoat for deeper blacks on glossy media. The printer includes 110 mL starter cartridges and a retractable catch basket, and Epson lists a maximum roll print length of 708.66 inches.

SureColor P9570 key specifications

Print width	44 in roll and cut sheet
Printhead	12-channel PrecisionCore MicroTFP, 2.6 in, 9,600 nozzles (800 x 12)
Max resolution / droplet	2400 x 1200 dpi / 3.5 pl
Ink	Epson UltraChrome PRO12 pigment, 12 colors incl. Orange, Green, Violet, Photo Black and Matte Black
Ink cartridges	110 mL in the box; retail 150 mL (T44W), 350 mL (T44P), 700 mL (T44H)
Speed (Epson spec, 23.4 x 33.1 in)	2:02 with Black Enhance Overcoat off; 4:04 with it on
Max roll length	708.66 in
Interfaces	Gigabit Ethernet, USB 2.0, internal hard-drive slot; 4.3 in touchscreen
Weight / size	339 lb; 75.1 x 26.3 x 48 in with basket closed
Noise	About 49.5 dB(A)
Warranty	1-year limited; on-site repair is usually next business day

What the SureColor P9570 is used for

• Large fine art and giclee prints, canvas wraps and gallery pieces
• Photography enlargements for exhibitions and retail
• Color-critical proofing and spot-color reference work
• Production runs on roll media with an optional take-up reel

Who buys the SureColor P9570 and what they print

Who buys it, from DTG’s sales and support work in Tampa: Epson SureColor P-series printers like the P9570 are bought by art publishers, fine art reproduction shops, giclee printers and artists; photographers (commercial, portrait, landscape and fine art); photo fulfillment shops and galleries; and commercial offset printers, ad agencies and corporate in-plant graphics departments that use them for color proofing.

What they print on: photo papers (luster, gloss, semigloss, semi-matte, fiber and baryta), artist canvas (gloss, matte and satin) and fine art papers (smooth and textured). Browse fine art and giclee media and photo media, or ask DTG which papers fit the P9570.

P9570 vs P9370 vs P8570D: choosing a 44-inch Epson P-series

The P9570 is the PRO12 model among the 44-inch Epson P-series printers. The P9370 uses ten-color PRO10, while the P8570D and P8570DL use six-color PRO6 and add dual-roll loading with the Adobe Embedded Print Engine. If your work depends on the widest color coverage, such as fine art reproduction or spot-color matching, the P9570 is the model Epson positions for that. If you print PDF-based production work from two loaded rolls, the P8570D family is the better fit.

Is the SureColor P9570 the right size? DTG’s advice

“Which size should I buy?” is the question DTG hears most before a sale. For most print businesses our answer is 44 inches wide: it is the sweet spot. The most common mistake we see is buying too narrow. Almost every customer who buys a 24-inch printer and succeeds with it ends up upgrading to 44 inches, so if you expect your print work to grow, size up now.

The P9570 is a 44-inch printer, the width DTG recommends for most print businesses. The other 44-inch P-series models are the SureColor P9370 and P8570D.

Before you buy, DTG walks you through cost per print and cost per square foot for the work you plan to do. Call a print specialist at 656.232.1877.

Ink, media, software and service for the SureColor P9570

• Ink: Epson ink for the P9570 is UltraChrome PRO12 in T44H 700 mL, T44P 350 mL and T44W 150 mL cartridges (Photo Black shown; all twelve colors available).
• Media: Epson Premium Luster Photo Paper 44 in, Enhanced Matte Paper 44 in, Hot Press Natural 44 in and Standard Proofing Paper II 44 in. See fine art and giclee media.
• RIP software: the Mirage Master Edition for Epson product page lists the SureColor P5xxx, P6xxx, P7xxx, P8xxx and P9xxx families among supported printers; ask DTG to confirm your exact model before ordering. Other options are under RIP software (ONYX, ImagePrint, EFI Fiery XF).
• Color management: spectrophotometers, profiling systems and DTG’s ICC profile library help you match prints to your display and proof.
• Custom ICC profiles: free custom ICC profiles from DTG for customers who buy the P9570 from DTG, built for your papers; call DTG at 656.232.1877 for details.
• Optional hardware: automatic take-up reel system, 320 GB internal hard drive, PostScript module and additional roll adapters.
• Service: Epson Preferred Plus extended service plans are available for the P9570 at time of hardware purchase (1-year, 2-year and 4-year); plan terms are set by Epson. Browse more under warranties and service plans.
• Epson drivers, manuals and support for the P9570
• Epson US product page for the P9570

What DTG does after the sale

Buy your SureColor P9570 from DTG (Digital Technology Group) at the DTG Technology Center in Tampa, FL, and you get more than a box:

• Installation and training: available for every printer DTG sells (for a fee).
• Tech support: free toll-free tech support from DTG.
• Custom ICC profiles: free custom ICC profiles from DTG, built for your P9570 and the papers you use.
• Color management expertise from DTG’s print specialists.
• Ink, media and support available from DTG.
• More than 30 years of digital printing expertise.

Call a print specialist at 656.232.1877 or contact us online.

SureColor P9570 FAQ

How wide is the Epson SureColor P9570?

It is a 44-inch wide-format printer for roll and cut-sheet media.

What is the difference between the P9570 and P9370?

Both are 44-inch Epson printers. The P9570 uses twelve-color UltraChrome PRO12 with Orange and Green; the P9370 uses ten-color UltraChrome PRO10 with Violet.

What ink sizes does the P9570 use?

It ships with 110 mL cartridges. Retail cartridges are 150 mL, 350 mL and 700 mL in all twelve colors.

How fast is the P9570?

Epson lists 2:02 Normal with Black Enhance Overcoat off and 4:04 with it on for a 23.4 x 33.1 inch print. Actual speeds vary by media, settings and workflow.

Where can I get P9570 support in Tampa, FL?

DTG (Digital Technology Group) is in Tampa, FL. Call 656.232.1877 for P9570 ink, media, accessories and service plans.

Why does DTG recommend a 44-inch printer like the P9570?

Callers ask which size to buy more than anything else, and for most print businesses DTG recommends 44 inches wide: it is the sweet spot. Almost every customer who buys a 24-inch printer and succeeds with it ends up upgrading to 44 inches. Call 656.232.1877 and DTG will work through cost per print and cost per square foot for your work.

Is the 12-color ink set on the P9570 right for my work?

It depends on what you print. The P9570 uses 12-color Epson UltraChrome PRO12 pigment ink. Epson’s current P-series ink sets are 6-color PRO6 (P6570 and P8570 families), 10-color PRO10 (P700, P900, P5370, P7370 and P9370) and 12-color PRO12 (P7570, P9570 and P20570). Tell a DTG print specialist what you print and we will recommend the right ink set.

What papers and canvas do DTG customers print on with the P9570?

P-series customers at DTG print on photo papers (luster, gloss, semigloss, semi-matte, fiber and baryta), artist canvas (gloss, matte and satin) and fine art papers (smooth and textured). Ask DTG which papers and sizes fit the P9570.

What does DTG provide after I buy a P9570?

Installation and training are available for every printer DTG sells, for a fee. Tech support on DTG’s toll-free line is free, and DTG builds free custom ICC profiles for customers who buy a P-series printer from DTG. You also get DTG’s color management expertise and more than 30 years of digital printing experience.

Does DTG make custom ICC profiles for the Epson SureColor P9570?

Yes. DTG builds free custom ICC profiles for customers who buy the P9570 from DTG, matched to your papers and workflow. Call DTG in Tampa at 656.232.1877 for details.

Where do I download the Epson SureColor P9570 driver?

Epson posts the current P9570 drivers and manuals for Windows and Mac on its official Epson SureColor P9570 support page. If you bought your P9570 from DTG, tech support on DTG’s toll-free line is free. Call DTG in Tampa at 656.232.1877 with driver questions.

Is the P9370 good enough, or do I need the P9570?

It depends on who you print for. For consumer-grade photography or artwork, DTG finds the 10-color P9370 is plenty. If you print for professional photographers or artists, the wider color gamut of the 12-color P9570 is a must: its Epson UltraChrome PRO12 ink adds Orange and Green to the ten colors the P9370 uses. And if you run a print service, your competition is printing on the best equipment, so you need the best too. Call DTG at 656.232.1877 to talk through your work.

How does the Epson P9570 compare to the Canon imagePROGRAF PRO-4600?

DTG sells both, and both produce high-quality, sellable prints. The biggest difference is the printhead. The P9570 uses an Epson PrecisionCore MicroTFP piezo printhead, which Epson designs to last the life of the printer; it is not a part you replace. The Canon PRO-4600 uses thermal printheads that the owner replaces periodically as a consumable, and Canon adds built-in calibration. In DTG’s experience piezo heads are a bit more accurate and consistent, though Canon has improved its thermal technology. In our humble opinion, the Canon is probably a little stronger on glossy photo paper, and the Epson P9570 is stronger on fine art paper and canvas.

Is the P9570 a good printer for color proofing?

Yes. DTG considers the P9570 with Epson’s optional in-line 44-inch SpectroProofer UVS the gold standard for proofing. Epson lists the SpectroProofer as compatible with the P9570 (44-inch) and the P7570 (24-inch); it measures color right on the printer and needs a supported third-party RIP. For proofing, DTG recommends staying with the P7370/P9370 or P7570/P9570 platform, which offers a wider gamut for Pantone colors and the most accurate proofs. DTG does not recommend the P6570 or P8570 family for proofing.

How many prints will I get from the starter ink that comes with my printer?

It depends on what you print, since some colors run out faster than others. Light Black (gray) usually goes first, because it’s used across the whole tonal range, even in color prints. The wide-gamut colors last longer, depending on your files. From our installs here at DTG, plan on about 10 to 15 24×36″ prints before you need a new Light Black cartridge. If you print every day or every other day, buy a full ink set with your printer or soon after.

How much maintenance does a SureColor P- or T-series printer need?

Very little. You’ll change ink, load paper and replace the maintenance tank. We recommend cleaning around the capping station and printhead area about every 6 months. Do it a little more or less often depending on how much you print.

Why is my print a slightly different size than my file?

Print length can vary a little depending on your media and settings. Our video with Mirage on print length correction shows why it happens and how to fix it.

Questions about the SureColor P9570? Call DTG in Tampa, FL at 656.232.1877 or contact us online.
