Summa S3T120 S Class 3 Tangential Cutter, 48″

$8,690.00 or finance as low as $260.70/monthApply Now

  • Summa S3T120 S Class 3 Tangential Cutter, 48"
  • Maximum media width: 127cm / 50"
  • Cutting technology: Tangential cutting knife
  • Max cutting thickness: 1.2 mm / 0.047"
Add to Wishlist
Add to Wishlist
SKU: S3T120

Description

The Summa S3T120 S Class 3 Tangential Cutter, 48″ is Summa’s S3T120 — the S3 120 S3 T Series true tangential cutting head.

Summa’s brochure describes the Summa S3 120 as the mid-size cutter in the S3 Series and “the ideal choice for medium-scale projects, such as non-prismatic traffic signs and internal signage.” The S3 120 key-features text says it handles media up to 47.2 in, plus 2.8 in in oversized mode.

Summa’s brochure assigns the S3 T Series a “True Tangential cutting head.” It says the S Class 3 T Series “combines S Class power and precision with a state-of-the-art True Tangential cutting head.” The comparison table lists S3 T Series cutting technology as True Tangential Knife.

Summa’s S3T series page describes the S3T as bringing “tangential precision to roll based production” and names floor graphics, PPF, laminated prints, stencil films and light cardboard among the materials it discusses for that series.

The S3 technical specifications table lists knife pressure as “Drag Knife: Up to 400 grams / Tangential Knife: Up to 1000 grams.” This model is the T-series tangential variant, so the published tangential figure is up to 1000 grams.

Included software on the S3 technical specifications table is Summa GoSign Software and Summa Cutter Control, with plug-ins for Illustrator, CorelDraw, and MacSign. The brochure says “GoSign is your first choice cutting software designed for the Summa roll cutters” and that it allows you to manage a preferred workflow with flexibility.

S3T120 specifications

These figures come from Summa’s S3 technical specifications table and the S3 size-class pages in the 2026 vinyl cutter brochure (RevEN(US)25.10). Media width and maximum working width are listed separately in that table; they are not the same measurement.

Summa model S3T120
S3 size class S3 120
Cutting technology True Tangential Knife
Dimensions 187 x 69 x 111 cm (73.6" x 27.2" x 43.7")
Media width 4.5" to 51.1"
Max. working width 120 cm x 50 m (47.2" x 164 ft); oversized mode allows a wider cutting area of ±7 cm (2.8")
Comparison-table maximum media width 130 cm (51")
Pinch rollers 3
Alignment OPOS X – OPOS Xtra; barcode job recognition; up to 2 × 64 marks on the X-line; Y-Line compensation
Tracking performance 12 m (40 ft) max. within guaranteed specifications for media less than 762 mm (30"); 4 m (13 ft) max. for media larger than 762 mm (30"). Oversized mode: tracking no longer guaranteed.
Media thickness 0.05 mm (0.002") to 0.25 mm (0.01"); up to 0.8 mm (0.03") with sandblast drag knife; up to 1.2 mm (0.047") with sandblast tangential knife
Accuracy 0.2% of movement or 0.25 mm (0.010"), whichever is greater
Speed Up to 1440 mm/s (56"/s) diagonal
Acceleration Up to 4.25 G diagonal
Knife pressure Drag knife: up to 400 grams / tangential knife: up to 1000 grams
Other features FlexCut (cutting through)
Connectivity Ethernet, USB, WIFI
Power requirements 100–120 / 220–240 VAC, 50/60 Hz, 85 VA maximum
Included software Summa GoSign Software, Summa Cutter Control; plug-ins for Illustrator, CorelDraw, MacSign

Related Summa S Class 3 products

Sources: Summa 2026 Vinyl Cutter Brochure (RevEN(US)25.10); Summa S3T series page.

FAQ

What cutting technology does the S3T120 use?

True Tangential Knife, as listed for the S3 T Series in Summa’s 2026 vinyl cutter brochure.

What are the official S3 120 media and working widths?

The S3 technical specifications table lists media width 4.5" to 51.1" and maximum working width 120 cm x 50 m (47.2" x 164 ft). Oversized mode adds ±7 cm (2.8"); tracking is not guaranteed in oversized mode. The comparison table’s maximum media width for this size is 130 cm (51").
