Description
General Formulations GF 830 AutoMark™ Cast 2.0 mil Gloss White Wrap Vinyl with Slidable Repositionable Air Egress Adhesive
GF 830 AutoMark™ Cast with DRIFT® Technology is a 2.0 mil High Gloss White Cast film with a slidable and repositionable grey adhesive system. The DRIFT Technology and air egress feature provides installers the benefit of a slidable and bubble-free installation. The repositionable grey long-term removable adhesive delivers excellent opacity for color blocking possible substrate bleed through. GF 830 is specifically engineered for automotive OEM paint, complex curves, rivets, and perfect for vehicle and fleet applications. Compatible with a variety of solvent, eco-solvent, latex and UV curable inks.
Specifications
| Film Type | Cast White Vinyl |
|---|---|
| Film Thickness (mil) | 2.0 |
| Adhesive | Solvent Acrylic |
| Release Liner | White PE-Coated Kraft, Slidable Air Egress |
| Outdoor Durability | Up to 8 years |
Applications
General Formulations lists GF 830 for signage (general), vehicle and transit.
- General Signage
- Vehicle Graphics
- Transit Advertising
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 830-54 | 54″ x 150′ |
| 830-60 | 60″ x 150′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
Can I use AutoMark™ Cast w/DRIFT® Technology for full vehicle wraps?
Yes. This is a wrapping film perfect for complex curves, deep channels, rivets, and false recesses.
What does “slidable” mean?
The slidable adhesive allows you to literally slide the film on the OEM painted surface and easily reposition as needed. Once pressure is applied to the film surface, the adhesive is then activated.
What are “air-egress” channels?
GF 830 has a slidable air-egress liner. This liner has a micro-embossed pattern that is transferred to the adhesive and creates air-egress channels. During application, the air-egress channels permit entrapped air to be squeegeed out easily resulting in a bubble free application.
Can GF 830 be used on fiberglass boats?
Yes. If all Fluorinated waxes are completely removed.
Can GF 830 be used on ceramic coatings?
No. GF 830 will not stick to any ceramic coating.
