Description
General Formulations GF 238 MotoMark® ARMOR 12.0 mil Gloss UV Laminate with Clear Permanent Adhesive
GF 238 MotoMark® “ARMOR” 12.0 mil is a flexible gloss clear laminate that offers UV protection and is designed for use as a protective overlaminating film when used in combination with GF 235 MotoMark® “GRIP” vinyl. MotoMark® is recommended for a variety of applications including Quads, Snowmobiles, Motocross, Powersport Vehicles, Helmets and Carts. The adhesive system is formulated to adhere to most common solvent, eco-solvent, latex, thermal, UV, offset and screen inks.
Specifications
| Film Type | Clear Monomeric Vinyl |
|---|---|
| Film Thickness (mil) | 12 |
| Adhesive | Solvent |
| Release Liner | White PE-Coated Kraft |
| Outdoor Durability | Up to 5 years |
Applications
General Formulations lists GF 238 for signage (general) and vehicle.
- General Signage
- Vehicle Graphics
Roll sizes
| GF part # | Size |
|---|---|
| 238-24 | 24″ x 75′ |
| 238-30 | 30″ x 75′ |
| 238-54 | 54″ x 75′ |
| 238-60 | 60″ x 75′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
This is a very thick film, can my cutter cut through MotoMark®?
Most cutters, printer/cutters and cutting software have specific instructions on how to achieve this. General Formulations has a set of general guidelines on this topic. Please see our website and under technical tips see “Cutting Thicker Materials”.
Will GF 238 adhere to all ink types?
The adhesive system is formulated to adhere to most common solvent, eco-solvent, latex, thermal, UV, offset and screen inks. However, specific formulations must be tested before use. Some ink may contain excessive flow additives that could reduce adhesion of this product. Testing is always suggested before production.
What roll sizes does DTG offer for GF 238?
DTG offers 24" x 75' (GF 238-24), 30" x 75' (GF 238-30), 54" x 75' (GF 238-54), 60" x 75' (GF 238-60).
Related General Formulations products
- GF 235 MotoMark® GRIP 4.0 mil Matte White Vinyl
- GF 240 AutoMark™ 2.4 mil Matte UV Laminate with Clear Permanent Adhesive
- GF 242 OptiMark™ Cast 2.0 mil Gloss Optically Clear UV Laminate with Optically Clear Permanent Adhesive
- GF 231 AutoMark™ 2.4 mil Gloss UV Wrap Laminate with Clear Permanent Adhesive
- GF 217 Traffic Graffic® 3.0 mil Gloss Clear Vinyl Floor Laminate with Clear Permanent Adhesive
All General Formulations media at DTG
General Formulations GF 238 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
Questions about GF media? Call DTG (Digital Technology Group) in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online.
