Description
General Formulations GF 235 MotoMark® GRIP 4.0 mil Matte White Vinyl
GF 235 MotoMark® 4.0 mil “GRIP” is specially formulated premium flexible matte white PVC film. This film has a unique “High Bond” solvent acrylic pressure sensitive adhesive with a 90# layflat liner. The adhesive is formulated for the powersport graphic and decal markets. GF 235 MotoMark® can be printed on a variety of solvent-based, latex, UV and thermal printers that are commonly used in wide format. This product may also be printed on using other printing processes such as UV screen and UV curable offset but must be tested before production.
Specifications
| Film Type | White Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 4.0 |
| Adhesive | Solvent Acrylic |
| Release Liner | White 2-Sided PE-Coated Kraft |
| Outdoor Durability | Up to 5 years |
Applications
General Formulations lists GF 235 for signage (general) and vehicle.
- General Signage
- Vehicle Graphics
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 235-24 | 24″ x 150′ |
| 235-30 | 30″ x 150′ |
| 235-54 | 54″ x 150′ |
| 235-60 | 60″ x 150′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What does LSE mean?
LSE is an abreviation for Low Surface Energy. Historically low surface energy plastics include thermoplastic polyolefin (TPO), polypropylene (PP) and polyethylene (HDPE). These plastics are very hard to stick to and require special high-tack adhesives. Most powersports vehicles, carts & helmets are made with these types of plastics.
Is MotoMark®a full wrap film?
No. When GF 235 MotoMark® is used with our GF 238 MotoMark® Laminate, you will have a 15-16 mil construction which (although conformable) is extremley difficult to wrap around curves and deep recesses.
What types of vehicles are ideal for GF 235 MotoMark®?
GF 235 is designed to be applied to quads, snowmobiles, motocross, powersport vehicles, helmets, and carts. Recommend testing before application.
What are the recommended laminates for GF 235?
GF 238 MotoMark® Laminate is the matching laminate and provides the most protection for the helmet and powersport types of applications.
Can I use primer with this product?
We do not recommend Primer 94 with our product. If absolutely necessary a small amount of Pro Bond™ Adhesive Promoter may be used in the tougher areas, but best practices are to clean the surface and crevices thoroughly, as most failures are the result of dirt and debris.
Related General Formulations products
- GF 238 MotoMark® ARMOR 12.0 mil Gloss UV Laminate with Clear Permanent Adhesive
- GF 234 GraphiTex™ 7.0 mil Matte White Polyester Fabric with Clear Repositionable Wall Adhesive
- GF 232 WindowMark™ 6.0 mil Matte White Perforated Vinyl (50/50) with Clear Removable Adhesive
- GF 230 AutoMark™ 2.4 mil Gloss White Wrap Vinyl with Grey Repositionable Adhesive
- GF 229 WallMark® Canvas 6.0 mil Matte White Embossed Vinyl with Clear Repositionable Wall Adhesive
All General Formulations media at DTG
General Formulations GF 235 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
Questions about GF media? Call DTG (Digital Technology Group) in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online.
