Description
General Formulations GF 231 AutoMark™ 2.4 mil Gloss UV Wrap Laminate with Clear Permanent Adhesive
GF 231 is a premium 2.4 mil calendered gloss clear laminate with a clear permanent acrylic adhesive on a 53# PE coated kraft liner. This laminate offers protection from ultra violet radiation, moisture and other environmental exposures. It is can be laminated by using a cold laminating process without the addition of heat and is intended to be paired with GF 230 AutoMark™ vinyl for wrap applications. GF 231 AutoMark™ premium 2.4 mil calendered gloss laminate is specifically engineered for use in most vehicle wrap and decal applications.
Specifications
| Film Type | Clear Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 2.4 |
| Adhesive | Solvent Acrylic |
| Release Liner | White PE-Coated Kraft |
| Outdoor Durability | Up to 7 years |
Applications
General Formulations lists GF 231 for signage (general), vehicle and transit.
- General Signage
- Vehicle Graphics
- Transit Advertising
Roll sizes
| GF part # | Size |
|---|---|
| 231-54 | 54″ x 150′ |
| 231-54300 | 54″ x 300′ |
| 231-60 | 60″ x 150′ |
| 231-60300 | 60″ x 300′ |
Per General Formulations, 300' rolls may contain a splice. Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What are the intended applications for GF 231?
This laminate is best suited for long-term outdoor graphics. GF 231 AutoMark™ Wrap Laminate was created to be paired with GF 230 AutoMark ™ Wrap Vinyl to create long lasting outdoor graphics for vehicle wrap and decal applications.
Can I use GF 231 AutoMark™ laminate with other print vinyls?
GF 231 will work well with most base vinyls, however for optimal success you will want to pair similar products together.
Can I use a laminate other than GF 231 AutoMark™ Wrap Laminate with GF 230 AutoMark™ Wrap Vinyl?
Although other laminates may work, the warranty outlined by General Formulations is only in effect if the warranted AutoMark™ products are used. The AutoMark™ series of laminates are customize for this specific application (2.4 mil polymeric vinyls ideal for simple curves) We recommend filling out the application checklist on our website to ensure a successful installation. Videos are available on YouTube as well that outline specific techniques.
Related General Formulations products
- GF 230 AutoMark™ 2.4 mil Gloss White Wrap Vinyl with Grey Repositionable Adhesive
- GF 238 MotoMark® ARMOR 12.0 mil Gloss UV Laminate with Clear Permanent Adhesive
- GF 240 AutoMark™ 2.4 mil Matte UV Laminate with Clear Permanent Adhesive
- GF 242 OptiMark™ Cast 2.0 mil Gloss Optically Clear UV Laminate with Optically Clear Permanent Adhesive
- GF 217 Traffic Graffic® 3.0 mil Gloss Clear Vinyl Floor Laminate with Clear Permanent Adhesive
All General Formulations media at DTG
General Formulations GF 231 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
