Description
General Formulations GF 229 WallMark® Canvas 6.0 mil Matte White Embossed Vinyl with Clear Repositionable Wall Adhesive
GF 229 WallMark® Canvas is a 6.0 mil embossed matte white semi-rigid calendered vinyl film. This product has a specially formulated microsphere acrylic pressure sensitive adhesive designed for ease of removal, repositioning and reuse, and is backed by a 90# layflat liner. The combination of vinyl and adhesive is designed for use on smooth wall surfaces. The 90# tight release liner provides excellent stability for processing using standard solvent, latex, and UV curable inks common to wide format digital printing systems.
Specifications
| Film Type | White Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 6.0 |
| Adhesive | Emulsion Acrylic |
| Release Liner | White 2-Sided PE-Coated Kraft |
| Indoor Durability | 5 years |
Applications
General Formulations lists GF 229 for signage (POP and indoor) and walls.
- POP & Indoor Signage
- Walls
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 229-54 | 54″ x 100′ |
| 229-60 | 60″ x 100′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
Can I use GF 229 on other surfaces?
GF 229 is designed for wall murals, decals and graphics on most types of smooth painted interior walls. This includes most flat, semi-gloss and gloss paint finishes. The surface must be smooth and clean prior to application. If applying to new paint consult the paint manufacturer for proper curing conditions before GF 229 application.
What if I leave the GF 229 WallMark® on past it’s optimal removability time frame?
The adhesive on this product will build for a few days and then it will reach its optimal bond. It will not get more aggressive over time because of the low-tack/microsphere adhesive technology.
Can this product be used on Elevators?
While the adhesive on GF 229 will stick to stainless steel and other polished metal surfaces, these types of doors may have a clear coat or other type of protection that can ‘ghost’ when the decal is removed. Any ghosting can potentially be cleaned with a metal polish, but it is best to test a small piece in an inconspicuous area for 24 hours prior to full installation to confirm fitness for use.
When paneling larger jobs, do I use overlaps or butt-seams with this product?
Either is acceptable, although butt seams require a high degree of skill to line up the panels. For this product a larger than normal overlap is usually recommend. This accomplishes two things: allows for a large area of adhesion and mitigates the “bump” caused by the two sections overlapping. We recommend 2-3” for overlapping panels.
Related General Formulations products
- GF 229HTR WallMark® Canvas 6.0 mil Matte White Embossed Vinyl with High-tack Removable Wall Adhesive
- GF 228 TransMark™ 6.0 mil Matte White Translucent Vinyl with Clear Removable Adhesive
- GF 230 AutoMark™ 2.4 mil Gloss White Wrap Vinyl with Grey Repositionable Adhesive
- GF 227 WallMark® Lite 3.4 mil Matte White Vinyl with Clear Repositionable Wall Adhesive
- GF 226 WallMark® 6.0 mil Matte White Vinyl with Clear Repositionable Wall Adhesive
All General Formulations media at DTG
General Formulations GF 229 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
