Description
General Formulations GF 201HTAP 3.4 mil Matte White Vinyl with Clear High-tack Permanent Adhesive
GF 201HTAP is a 3.4 mil polymeric matte white calendered vinyl coated with a clear acrylic high-tack permanent adhesive (HTAP) on a 90# layflat liner. This vinyl is designed to accept a variety of solvent, eco-solvent, UV curable and latex digital inks common to wide format digital printing systems. The HTAPAE adhesive can be adhered to a variety of substrates such as metals, painted metals, smooth wood, plywood, primed MDO board and vinyl. It also works well on ABS, styrene, polyester, polycarbonate and smooth polyolefins. The 90# liner offers excellent product layflat in a variety of ambient conditions.
Specifications
| Film Type | White Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 3.4 |
| Adhesive | Emulsion Acrylic |
| Release Liner | White 2-Sided PE-Coated Kraft |
| Outdoor Durability | Up to 5 years |
Applications
General Formulations lists GF 201HTAP for signage (general, POP and indoor) and walls.
- General Signage
- POP & Indoor Signage
- Walls
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 201HTAP-54 | 54″ x 150′ |
| 201HTAP-54300 | 54″ x 300′ |
| 201HTAP-60 | 60″ x 150′ |
| 201HTAP-60300 | 60″ x 300′ |
Per General Formulations, 300' rolls may contain a splice. Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What applications GF 201HTAP intended for?
GF 201HTAP is ideal for exterior signage, decals, nameplates and point-of-purchase displays. It can be adhered to a variety of substrates such as metals, painted metals, smooth wood, plywood, primed MDO board and vinyl. It also works well on ABS, styrene, polyester, polycarbonate and smooth polyolefins.
Can GF 201HTAP be removed?
GF 201HTAP has an aggressive clear high-tack adhesive that that bond well to hard-to-stick to surfaces. This adhesive is permanent and will not remove cleanly.
What inks is GF 201HTAP compatible with?
General Formulations lists these ink types for GF 201HTAP: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Related General Formulations products
- GF 201 3.4 mil Matte White Vinyl with Clear Permanent Adhesive
- GF 201HTAPAE 3.4 mil Matte White Vinyl with Clear High-tack Permanent Adhesive
- GF 201OP 3.4 mil Matte White Vinyl with Grey Permanent Opaque Adhesive
- GF 201OPAE 3.4 mil Matte White Vinyl with Grey Permanent Opaque Adhesive
- GF 201QS Quick-Split™ 3.4 mil MATTE WHITE VINYL
All General Formulations media at DTG
General Formulations GF 201HTAP technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
Questions about GF media? Call DTG (Digital Technology Group) in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online.
