Description
General Formulations GF 201HTAPAE 3.4 mil Matte White Vinyl with Clear High-tack Permanent Adhesive
GF 201HTAPAE is a 3.4 mil polymeric matte white calendered vinyl coated with a clear acrylic high-tack permanent adhesive (HTAP) on a 90# air-egress (AE) layflat liner. This vinyl is designed to accept a variety of solvent, eco-solvent, UV curable and latex digital inks common to wide format digital printing systems. The HTAPAE adhesive can be adhered to a variety of substrates such as metals, painted metals, smooth wood, plywood, primed MDO board and vinyl. It also works well on ABS, styrene, polyester, polycarbonate and smooth polyolefins. The 90# liner offers excellent product layflat in a variety of ambient conditions along with ease of application of large format graphics.
Specifications
| Film Type | White Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 3.4 |
| Adhesive | Emulsion Acrylic |
| Release Liner | White 2-Sided PE-Coated Kraft, Air-Egress |
| Outdoor Durability | Up to 5 years |
Applications
General Formulations lists GF 201HTAPAE for signage (general, POP and indoor) and walls.
- General Signage
- POP & Indoor Signage
- Walls
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 201HTAPAE-54 | 54″ x 150′ |
| 201HTAPAE-60 | 60″ x 150′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What applications is GF 201HTAPAE intended for?
GF 201HTAPAE is ideal for exterior signage, decals, nameplates and point-of-purchase displays. It can be adhered to a variety of substrates such as metals, painted metals, smooth wood, plywood, primed MDO board and vinyl. It also works well on ABS, styrene, polyester, polycarbonate and smooth polyolefins. (NOTE: Air-Egress adhesives are DRY APPLY ONLY).
Can GF 201HTAPAE be removed?
GF 201HTAPAE has an aggressive high-tack adhesive that bond well to hard-to-stick to surfaces. This adhesive is permanent and will not remove cleanly.
What inks is GF 201HTAPAE compatible with?
General Formulations lists these ink types for GF 201HTAPAE: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
