Description
General Formulations GF 109 Traffic Graffic® 5.0 mil Scratch Resistant Textured Matte Vinyl Floor Laminate with Clear Permanent Adhesive
GF 109 is a 5.0 mil scratch resistant clear laminate with a textured matte finish. This laminating film is an inexpensive and durable alternative to polycarbonate film. It has a permanent acrylic pressure sensitive adhesive formulated for exceptional clarity. Produced on a 1.5 mil polyester clear liner, the laminate has an extremely smooth adhesive coating. GF 109 can be paired with approved print films to create graphics for tile and carpet. GF 109 has been rated for slip resistance based on multiple testing methods. UL 410 approved for slip resistance on interior floors and commercial carpets.
Specifications
| Film Type | Clear Rigid Vinyl |
|---|---|
| Film Thickness (mil) | 5 |
| Adhesive | Solvent Acrylic |
| Release Liner | Clear Polyester |
| Outdoor Durability | Indoor only |
Applications
General Formulations lists GF 109 for signage (general, POP and indoor) and floors.
- General Signage
- POP & Indoor Signage
- Floors
Roll sizes
| GF part # | Size |
|---|---|
| 109-38 | 38″ x 150′ |
| 109-51 | 51″ x 150′ |
| 109-54 | 54″ x 150′ |
| 109-54300 | 54″ x 300′ |
Per General Formulations, 300' rolls may contain a splice. General Formulations price list note: UL410 Approved / See Slip Resistance Ratings on pg.12. Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What types of applications is GF 109 good for?
GF 109 is a scratch resistant vinyl overalminate intended for use in the GF Traffic Graffic® floor decals system as a protective overlaminate. The film is also great for counter mats, mouse pads, and any graphic needing lasting protection
Does GF 109 bond to all ink types?
The permanent adhesive is formulated to adhere to most common printing inks. However, specific formulations must be tested before use. Some ink may contain excessive flow additives that could reduce adhesion of this product. Test before production.
Can I use GF 109 with any base vinyl?
Yes, although for UL approved Traffic Graffic® floor applications you must pair GF 109 with either GF 210 (tile) or GF 212 (carpet) base vinyls.
Related General Formulations products
- GF 210 Traffic Graffic® 3.4 mil Matte White Vinyl with Clear Removable Adhesive
- GF 212 Traffic Graffic® 3.4 mil Matte White Vinyl with High-tack Removable Adhesive
- GF 108 Tedlar™ by DuPont® 1.0 mil Satin Clear Anti-graffiti UV Laminate with Clear Permanent Adhesive
- GF 110 EraseMark™ Pro 2.0 mil Commercial Grade Erase Gloss Clear Laminate with Clear Solvent Permanent Adhesive
- GF 111 EraseMark™ 2.0 mil Gloss Clear Polypropylene Laminate with Clear Permanent Adhesive
All General Formulations media at DTG
General Formulations GF 109 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
Questions about GF media? Call DTG (Digital Technology Group) in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online.
