Description
General Formulations GF 108 Tedlar™ by DuPont® 1.0 mil Satin Clear Anti-graffiti UV Laminate with Clear Permanent Adhesive
GF 108 Tedlar™ by DuPont® is a satin clear 1.0 mil transparent PVF film coated with a solvent permanent pressure sensitive adhesive on a 53# liner. Recommended for use in smooth substrate laminating applications requiring extended resistance to UV exposure, color stability or abrasion resistance. GF 108 made with Tedlar™ is graffiti resistant.
Specifications
| Film Type | Clear Tedlar PVF Film |
|---|---|
| Film Thickness (mil) | 1.0 |
| Adhesive | Solvent Acrylic |
| Release Liner | White PE-Coated Kraft |
| Outdoor Durability | Up to 10 years |
Applications
General Formulations lists GF 108 for signage (general, POP and indoor), windows, walls, vehicle and transit.
- General Signage
- POP & Indoor Signage
- Windows
- Walls
- Vehicle Graphics
- Transit Advertising
Roll sizes
| GF part # | Size |
|---|---|
| 108-54 | 54″ x 150′ |
| 108-60 | 60″ x 150′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
Does GF 108 protect from UV rays?
GF 108 is designed to extend the exposure resistance of graphics, decals, and nameplates. This overlay will protect inks and graphics from fading caused by exposure to UV radiation.
What types of graffiti does GF 108 protect from?
GF 108 Tedlar™ film is resistant to permanent markers, spray paint, and harsh chemicals. Cleaners such as MEK and Acetone may be used and have no adverse effects on the film.
Will GF 108 Tedlar conform to a textured substrate or complex curves?
GF 108 Tedlar™ is designed for smooth surface and substrate applications only. The PVF film is not suitable for use as a laminate on textured print materials (such as WallMark® HTR textures or GraphiTex™ wall fabrics), and it will not conform to complex curves or rivets, even with heat.
Related General Formulations products
- GF 109 Traffic Graffic® 5.0 mil Scratch Resistant Textured Matte Vinyl Floor Laminate with Clear Permanent Adhesive
- GF 110 EraseMark™ Pro 2.0 mil Commercial Grade Erase Gloss Clear Laminate with Clear Solvent Permanent Adhesive
- GF 105 2.0 mil Gloss Optically Clear Laminate with Optically Clear Permanent Adhesive
- GF 111 EraseMark™ 2.0 mil Gloss Clear Polypropylene Laminate with Clear Permanent Adhesive
- GF 103 5.0 mil Clear Polycarbonate Textured Matte Laminate with Clear Permanent Adhesive
All General Formulations media at DTG
General Formulations GF 108 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
Questions about GF media? Call DTG (Digital Technology Group) in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online.
