Description
General Formulations GF 203OPAE 3.0 mil Gloss White Vinyl with Grey Permanent Opaque Adhesive
GF 203OPAE is a 3.0 mil polymeric gloss white flexible calendered vinyl film coated with a grey permanent solvent pressure sensitive adhesive with a 90# air-egress layflat liner. This film is designed to accept a variety of solvent-based inkjet and UV curable inks common to wide format digital printing systems. The grey adhesive creates a permanent bond to a variety of common substrates used in graphics applications. The 90# air-egress layflat liner offers excellent product layflat in a variety of ambient conditions along with ease of application of large format graphics.
Specifications
| Film Type | White Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 3.0 |
| Adhesive | Solvent Acrylic |
| Release Liner | White PE-Coated Kraft, Air Egress |
| Outdoor Durability | Up to 5 years |
Applications
General Formulations lists GF 203OPAE for signage (general, POP and indoor).
- General Signage
- POP & Indoor Signage
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 203OPAE-54 | 54″ x 150′ |
| 203OPAE-54300 | 54″ x 300′ |
| 203OPAE-60 | 60″ x 150′ |
| 203OPAE-60300 | 60″ x 300′ |
Per General Formulations, 300' rolls may contain a splice. Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What applications is GF 203OPAE intended for?
GF 203OPAE is designed for interior or exterior signage, decals, nameplates, point-of-purchase displays and added opacity with the grey opaque adhesive. The air-egress adhesive allows for bubble-free applications. (NOTE: Air-Egress adhesives are DRY APPLY ONLY).
Can GF 203OPAE be removed?
Most decals can be removed with some effort, even if they have a permanent adhesive. GF 203OPAE has a grey permanent solvent adhesive that works on a variety of surfaces. This adhesive is permanent and will not remove cleanly, but any adhesive transfer or residue can be cleaned up easily with standard adhesive removers.
Do I need a special application tape to remove cut shapes and graphics from the 203OPAE?
Many application/transfer tapes will stick to the face of the vinyl. For transporting graphics we would recommend an tape that sticks to the exposed air-egress liner. A product like Transferite® AirMask® 510U is an example of this type of premask.
Related General Formulations products
- GF 203 3.0 mil Gloss White Vinyl with Clear Permanent Adhesive
- GF 203HTAP 3.0 mil Gloss White Vinyl with Clear High-tack Permanent Adhesive
- GF 203HTAPAE 3.0 mil Gloss White Vinyl with Clear High-tack Permanent Adhesive
- GF 203OP 3.0 mil Gloss White Vinyl with Grey Permanent Opaque Adhesive
- GF 202 3.4 mil Matte White Vinyl with Clear Low-tack Removable Adhesive
All General Formulations media at DTG
General Formulations GF 203OPAE technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
