Description
General Formulations GF 203HTAPAE 3.0 mil Gloss White Vinyl with Clear High-tack Permanent Adhesive
GF 203HTAPAE is a 3.0 mil polymeric gloss white calendered vinyl coated with a clear acrylic high-tack permanent adhesive (HTAP) on a 90# air-egress (AE) layflat liner. This vinyl is designed to accept a variety of solvent, eco-solvent, UV curable and latex digital inks common to wide format digital printing systems. The HTAPAE adhesive can be adhered to a variety of substrates such as metals, painted metals, smooth wood, plywood, primed MDO board and vinyl. It also works well on ABS, styrene, polyester, polycarbonate and smooth polyolefins. The 90# liner offers excellent product layflat in a variety of ambient conditions along with ease of application of large format graphics.
Specifications
| Film Type | White Polymeric Vinyl |
|---|---|
| Film Thickness (mil) | 3.0 |
| Adhesive | Emulsion Acrylic |
| Release Liner | White PE-Coated Kraft, Air Egress |
| Outdoor Durability | Up to 5 years |
Applications
General Formulations lists GF 203HTAPAE for signage (general, POP and indoor) and walls.
- General Signage
- POP & Indoor Signage
- Walls
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 203HTAPAE-54 | 54″ x 150′ |
| 203HTAPAE-60 | 60″ x 150′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
What applications are GF 203HTAPAE intended for?
GF 203HTAPAE is ideal for interior or exterior signage, decals, nameplates, point of-purchase displays and general signage. It has superior bond to MDO Board, Powder coated metals, ABS, Sintra board, Coroplast, HDPE, Styrene, Polypropylene and Polyolefin.
Can GF 203HTAPAE be removed?
GF 203HTAPAE has an aggressive high-tack adhesive that can be used to stick to hard-to-stick to surfaces. This adhesive is permanent and will not remove cleanly.
What inks is GF 203HTAPAE compatible with?
General Formulations lists these ink types for GF 203HTAPAE: Solvent, Eco-Solvent, Latex, UV Curable, Screen, Offset (UV Curable).
Related General Formulations products
- GF 203 3.0 mil Gloss White Vinyl with Clear Permanent Adhesive
- GF 203HTAP 3.0 mil Gloss White Vinyl with Clear High-tack Permanent Adhesive
- GF 203OP 3.0 mil Gloss White Vinyl with Grey Permanent Opaque Adhesive
- GF 203OPAE 3.0 mil Gloss White Vinyl with Grey Permanent Opaque Adhesive
- GF 202 3.4 mil Matte White Vinyl with Clear Low-tack Removable Adhesive
All General Formulations media at DTG
General Formulations GF 203HTAPAE technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
