Description
The Canon imagePROGRAF TX-4300 prints up to 3.3 D-size (24″ x 36″) drawings per minute on plain paper, per Canon. It is a 44-inch, 5-color LUCIA TD pigment printer for CAD drawings, blueprints, GIS maps and posters. DTG in Tampa, FL sells, installs and supports it. Call DTG at 813.889.0660 or 800.681.0024.
How fast does the TX-4300 print a D-size drawing?
Canon rates the TX-4300 at up to 3.3 ANSI D prints per minute, measured after the first print in Fast Q5 mode on plain paper. Actual speed varies with copies, size, media type and orientation. Source: Canon U.S.A. TX-4300 product page.
TX-4300 specifications
| Print width | 44″ |
| D-size speed (Canon) | Up to 3.3 D/min (Fast Q5, plain paper) |
| Ink | 5-color LUCIA TD pigment: MBK, BK, C, M, Y |
| Starter ink | 330 ml MBK/BK/C/M/Y starter tanks |
| Replacement ink | 160, 330 or 700 ml tanks (PFI-110/111/113, PFI-310/311/313, PFI-710/711/713; Canon notes 700 ml is for service-authorized partners) |
| Printhead | PF-06, 15,360 nozzles (MBK 5,120; others 2,560 each), 2400 x 1200 dpi |
| Media | 6″ to 44″ roll and cut sheet, 0.07-0.8 mm thick |
| Max roll diameter | 6.7″ (170 mm) |
| Storage | 256 GB encrypted hard drive |
| Output | TX Stacker included; optional RU-44 Multifunction Roll System |
| Printer dimensions / weight | 62.7″ x 44.2″ x 46.0″ with stacker closed; 273.4 lbs. |
| Configuration | Printer with stand and TX Stacker |
Canon TX-4300 FAQ
What ink does the TX-4300 use?
It uses Canon’s 5-color LUCIA TD pigment ink (MBK, BK, C, M, Y). Out of the box you get 330 ml MBK/BK/C/M/Y starter tanks. Replacement tanks: 160, 330 or 700 ml tanks (PFI-110/111/113, PFI-310/311/313, PFI-710/711/713; Canon notes 700 ml is for service-authorized partners). You’ll find them on our Canon ink page.
What paper sizes and roll sizes does the TX-4300 take?
Canon lists 6″ to 44″ roll and cut sheet, 0.07-0.8 mm thick, with rolls up to 6.7″ (170 mm) outside diameter.
Does the TX-4300 come with a stand?
Yes. Per Canon, this configuration is the printer with stand and TX Stacker.
Which print head does the TX-4300 use?
It uses the PF-06 printhead: 15,360 nozzles (MBK 5,120; others 2,560 each), up to 2400 x 1200 dpi.
How do I buy a TX-4300 or get help with one?
Call DTG in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online. We’ll help you pick the right size, set it up, and keep you stocked on ink and paper.
Why buy the TX-4300 from DTG
DTG is an authorized Canon imagePROGRAF dealer in Tampa, FL. We help you pick the right technical printer for your drawing volume, set it up, and support it with ink, media and service. Call DTG at 813.889.0660 or 800.681.0024.
Specifications from Canon U.S.A.: TX-4300 spec sheet. Specifications subject to change by Canon.


Canon imagePROGRAF TX Series Brochure with Specifications (PDF)
