Description
Avery Dennison’s North America DOL 2000 Series product data sheet (Revision 11, dated 01/05/22) lists DOL 2060 as the gloss finish in that series. DOL 2000 Series films are “flexible vinyl films available in a gloss, luster, or matte finish” and “have been specifically designed as a protective overlaminate film for digital or screen printed graphics.”
Finishes on that sheet: DOL 2060 – Gloss; DOL 2070 – Luster; DOL 2080 – Matte. Face: 3.1 mil (79 microns) calendered film. Adhesive: permanent acrylic (clear). Liner: 78# bleached kraft. Application surfaces: flat or simple curves. Conversion: cold overlaminating.
Features listed include scratch protection; enhanced color and depth of image; durability and outdoor performance; aid in application of the printed graphic; UV, temperature, humidity, and salt-spray resistance; UL 410 slip resistance for floor surface materials; and an ASTM E84 Class 1 or A rating (the sheet repeats that Class 1 or A rating specifically for DOL 2060 and DOL 2080).
Common applications listed: fleet (flat and simple curve only); vehicle (flat and simple curve only); backlit; POP / trade show; wall murals; window graphics; outdoor signage; floor graphics.
When overlaminating UV printed graphics, the sheet says heat assist and increasing lamination pressure will reduce silvering, not to exceed 115°F (46°C) on the top or bottom roll, that roll pressure up to 100 psi may be used, and to use the minimum unwind tension to reduce stretching.
| Finish (DOL 2060) | Gloss; Hunter Gloss @ 60 degrees: 70 |
|---|---|
| Face | 3.1 mil (79 µm) calendered film |
| Adhesive | Permanent acrylic (clear); 1.0 mil (25 µm) |
| Liner | 78# bleached kraft |
| Dimensional stability | <0.025" (0.588 mm) |
| Adhesion, 15 min | 4.75 lbs/in (831 N/m) |
| Flammability | Self extinguishing; DOL 2060 ASTM E84 Class 1 or A |
| Slip resistance | UL 410 |
| Shelf life | 2 years from date of manufacture at 68°–77°F (20°–25°C) and 50±5% RH |
| Durability, vertical exposure | Up to 3 years; see ICS Performance Guarantee for printer-specific durability |
| Floor graphics durability | 6 months (normal and expected wear); see ICS Indoor Floor Graphics details |
| Min. application temperature | 40°F (4°C) |
| Service temperature | -40° to 180°F (-40° to 82°C) |
| Chemical resistance | Resistant to most mild acids, alkalis, and salt solutions including water; resists petroleum vapors |
| This listing’s roll description | 54" × 50 yards, 3" core (catalog) |
Related products
Source: Avery Dennison DOL 2000 Series Permanent Kraft PDS, Rev. 11, 01/05/22.
