UC900-360-T PERM PET-R, ORANGE, 48″ x 10 yd

$204.84

Avery UC Translucent Cast Vinyl UC900 48"x10 Yards
Add to Wishlist
Add to Wishlist
SKU: 9180TR

Description

Avery Dennison’s North America UC900 Ultimate Cast Series product data sheet (Revision 8, dated 12/03/20) lists UC900-360-T Orange on the color chart with 9 years of Zone 1 vertical durability. UC900 Ultimate Cast Translucent films are “high performance, flexible, translucent cast vinyl films which are especially suited for architectural graphic applications involving flexible and rigid backlit signage and awnings, as well as window graphics.” They “maintain consistent color under both transmitted and reflected lighting conditions.”

The sheet says these films should be applied to flexible backlit scrim, glass, polycarbonates, and acrylics (and should be tested prior to use). Application surfaces: flat. Face: 2.5 mil (64 microns) cast film. Adhesive: clear permanent acrylic. The sheet’s features list a PET liner for easy converting, wet application, and a smooth consistent finish; the physical table lists a 3.0 mil transparent liner.

Features also listed: outstanding durability and outdoor performance; matte finish; excellent conversion on CAD plotters; easy cutting and weeding; dimensional stability; UV, temperature, humidity, and salt-spray resistance. Conversion methods listed: thermal die-cutting; thermal transfer; steel-rule die-cut; thermoforming; flatbed sign-cut; drum roller sign-cut. Common applications listed: architectural signage; outdoor advertising; directional signage.

Color listed on PDS UC900-360-T Orange
Face 2.5 mil (64 microns) cast film
Adhesive Clear permanent acrylic; 1.0 mil (25 µm)
Liner PET / 3.0 mil transparent
Finish note Features list: matte finish; Hunter Gloss @ 60 degrees: 20 GU
Dimensional stability <0.015" (0.4 mm)
Elongation 100% min.
Adhesion 15 min 2.2 lbs/in (385 N/m); 24 hr 3.0 lbs/in (525 N/m)
Zone 1 vertical durability (UC900-360-T Orange) 9 years
Min. application temperature 40°F (4°C)
Service temperature -50° to 180°F (-45° to 82°C)
Shelf life 2 years from date of manufacture at 68°–77°F (20°–25°C) and 50±5% RH
This listing’s roll description 48" × 10 yards (catalog)

Source: Avery Dennison UC900 Ultimate Cast Translucent Permanent Transparent Synthetic PDS, Rev. 8, 12/03/20.
