HP Latex 54 Basic Plus Cutting Solution

Original price was: $4,495.00.Current price is: $3,999.00. or finance as low as $119.97/monthApply Now

Add to Wishlist
Add to Wishlist
SKU: 9TL93A

Description

The HP Latex 54 Basic Plus Cutting Solution (HP part 9TL93A) is an original HP stand-alone cutter for an HP Latex print and cut workflow. HP’s May 2021 Latex Plus Cutting Solutions datasheet (4AA7-1558ENA) describes it as the easy, affordable 54-inch cutting solution in that family.

HP describes these as a dual-device print AND cut workflow: add cut lines from the RIP, select cutting presets, and send the job to production. The datasheet notes you can print and cut at the same time, versus print-or-cut on an integrated printer/cutter. HP Latex prints can be cut without degas time. Accurate job recognition uses HP Barcode and Optical Position System configurations. The cutter has a touchscreen interface and a media basket.

HP FlexiPRINT and CUT RIP includes True Shape Nesting (HP’s demonstration, September 2020, compared printing without nesting and reported up to 50% more media saved). HP Applications Center design tools are included; they require an HP Applications Center account, an Internet connection, and a connected Internet-capable device.

HP states that each HP Latex Plus Cutting Solution can be directly connected to the HP Latex 100, 300, 500 and 700 Printer Series. Connecting to the HP Latex 800 Printer Series requires an upgrade of HP FlexiPRINT and CUT RIP.

HP Latex Plus cutter specifications

HP part number 9TL93A
HP name HP Latex 54 Basic Plus Cutting Solution
Maximum cut width 135 cm (53.1 in); HP notes this width is for standard media sizes
Maximum acceleration Up to 3G
Maximum cut speed Up to 113 cm/sec (44 in/sec) diagonal
Accuracy 0.2% of movement or 0.25 mm (0.01 in), whichever is greater
Cut force 0 to 400 grams of downforce, in 5-gram steps
Cut thickness 0.05 to 0.25 mm (0.002 to 0.01 in); 0.8 mm (0.03 in) with optional sandblast blade
Connectivity USB and Ethernet (LAN)
Cutter dimensions (W × D × H) 1765 × 704 × 1112 mm (69.5 × 27.7 × 43.8 in)
Cutter weight 43.5 kg (96 lb)
Shipping dimensions (W × D × H) 2230 × 420 × 710 mm (87.8 × 16.5 × 28 in)
Shipping weight 71 kg (156 lb)
Power AC 100–240 V; 50/60 Hz; 2 A; 34 W working mode
Warranty (HP) One-year limited hardware warranty
What’s in the box HP Latex cutter, cutter stand, media basket, HP FlexiPRINT and CUT RIP, HP Cutter Control software, quick reference guide, setup poster, documentation software, power cords, standard holder (1), standard blades (2), cut-off knife (1), and 3-in media flanges (set of 2)

HP lists applications including labels and stickers, customizable clothing, floor graphics, wall decals, window graphics, and vehicle graphics.
