Description
General Formulations GF 255 OptiMark™ 3.0 mil Gloss Optically Clear Vinyl with Clear Removable Adhesive
GF 255 OptiMark™ is a 3.0 mil optically clear high gloss flexible calendared PVC film coated with a clear solvent and removable pressure sensitive adhesive laminated to a 2.0 mil traction backed polyester liner. This film is designed to accept a variety of solvent-based, UV curable and latex inks common to wide format digital printing systems. The adhesive system provides clean removal from glass for up to one year under normal exposure conditions. The 2.0 mil polyester liner has a traction coating to aide in processing on common digital printers.
Specifications
| Film Type | Clear Monomeric Vinyl |
|---|---|
| Film Thickness (mil) | 3.0 |
| Adhesive | Solvent Acrylic |
| Release Liner | Clear Polyester |
| Outdoor Durability | Up to 3 years |
Applications
General Formulations lists GF 255 for signage (general, POP and indoor), windows and transit.
- General Signage
- POP & Indoor Signage
- Windows
- Transit Advertising
Ink and printer compatibility
Ink types listed by General Formulations: Solvent, Eco-Solvent, Latex, UV Curable, Screen.
Matching printers at DTG: Epson SureColor S-Series solvent printers, HP Latex and resin printers, UV flatbed printers. Confirm media settings with your printer and RIP profile.
Roll sizes
| GF part # | Size |
|---|---|
| 255-54 | 54″ x 150′ |
| 255-60 | 60″ x 150′ |
Durability statements are General Formulations estimates and do not constitute a written warranty; see the GF technical data sheet.
Frequently asked questions
Can I dry apply GF 255?
Yes, however wet applying GF 255 is the prefered method. Wet application on solvent based clear products is the best way to achieve bubble free and optically clear results. Dry applying is possilbe, but may result in some bubbles and/or reduction in optical clarity.
Can I use GF 255 on perforated vinyl since it is optically clear?
No. While GF 255 is optically clear, it is formulated with a removable adhesive and is not designed for conformable applications. GF 255 will not bond well to the perforated film and can create blurry air pockets in the perforations that will block the film’s one-way vision.
If I dont have a soft edged, Teflon coated, or wet edged squeegee can I use a regular squeege?
No. We do not recommend this. GF 255 is a clear calendared vinyl, and as such it will have a tendency to show squeegee marks. Regular squeegees may have burrs or uneven edges which may make impressions in the vinyl. Sometimes you “may” be able to heat these impressions out (depending on their severity), but we do not recommend heating the film on a cold glass surface, as cracking may occur. It is best to use a softer edge. You can also use a premask tape to protect the graphic during installation.
Related General Formulations products
- GF 260 WindowMark™ 6.0 mil Matte White Perforated Vinyl (60/40) with Clear Removable Adhesive
- GF 261 WindowMark™ 6.0 mil Gloss Clear Perforated Vinyl (60/40) with Clear Removable Adhesive
- GF 248 Print-N-Lam™ 3.0 mil Matte Clear UV Laminate with Clear Permanent Adhesive
- GF 262HTR WallMark® Sand 6.0 mil Matte White Embossed Vinyl with High-tack Removable Wall Adhesive
- GF 247 Print-N-Lam™ 3.0 mil Gloss Clear UV Laminate with Clear Permanent Adhesive
All General Formulations media at DTG
General Formulations GF 255 technical data sheet (PDF)
Product information from General Formulations (official product page). Specifications may change; check current GF literature for critical applications.
Questions about GF media? Call DTG (Digital Technology Group) in Tampa, FL at 813.889.0660 or 800.681.0024, or contact us online.
