Description
The ColorEdge CS3200X is the first 31.5-inch 4K model in the ColorEdge CS Series, offering creators a larger, more detailed workspace for video, photography, design, and print work. It combines 4K UHD (3840 x 2160) resolution on an IPS wide-gamut panel, 99% Adobe RGB and 96% DCI-P3 coverage, HLG and PQ HDR gamma, USB Type-C with up to 70 W of power delivery, and a bundled magnetic shading hood.
A calibration sensor is not built in to the CS3200X. This bundle includes the EIZO EX5 sensor, an external calibrator for hardware calibration with ColorNavigator 7. Call DTG toll-free at 800.681.0024 to confirm availability.
Detail, Depth, and Design
Color You Can Trust
Connectivity
Immersive Work Environment
Commitment to Quality
Specifications
Detail, Depth, and Design
Stunning 4K Detail Across a Large 31.5-inch Screen
The CS3200X’s generous screen size keeps timelines, layers, and tools comfortably in view, while the detailed 4K UHD (3840 x 2160) resolution renders images and video with crisp detail, allowing creators to discern fine textures and tonal transitions with greater precision.
HDR Gamma for Real-World Depth
The monitor supports both industry-standard transfer functions: Hybrid Log-Gamma (HLG) for broadcast and Perceptual Quantization (PQ) for film and streaming production. These gamma (EOTF) curves let you work with HDR content confidently throughout your workflow.
EOTF: Electro-Optical Transfer Function. HLG and PQ are standardized by ITU under ITU-R BT.2100, and PQ is also standardized by SMPTE under ST-2084.
Immersive 3-Sided Frameless Design
The 3-sided frameless design minimizes borders so your content stays in focus. As the first ColorEdge to adopt this look, the CS3200X brings a modern aesthetic and an immersive viewing experience to any creative workspace. Its fanless, noiseless operation further supports a calm and focused environment.
Color You Can Trust
Wide Gamut Ready for Every Workflow
The CS3200X’s wide color gamut covers 99% Adobe RGB and 96% DCI-P3 for faithful reproduction of key color spaces used across photography, video, print, and design. Preset modes for DCI-P3 and BT.709 support standard video workflows, while Display P3 ensures consistency with mobile devices and Apple computers. Each preset is easily accessible from the on-screen display.
Hardware Calibration for Continuous Precision
ColorNavigator 7 is EIZO’s dedicated color management software for maintaining color precision on your ColorEdge monitor. A dedicated calibration sensor is available as an optional accessory for intuitive and reliable calibration. Quick Color Match, EIZO’s screen-to-print color matching tool, is also supported.
Uniformity Across the Screen
EIZO’s patented Digital Uniformity Equalizer (DUE) technology ensures brightness and chromaticity remain consistent across the screen, countering the fluctuations common to LCD monitors that can affect color accuracy.
Precision Backed by Technical Expertise
The CS3200X delivers 10-bit display* powered by a 16-bit LUT, rendering more than a billion tones with fine accuracy and smooth gradations. Every unit is individually factory-adjusted so gamma behavior is consistent and predictable out of the box. A Factory Report is included with each CS3200X, detailing uniformity, gamma, gamut coverage, and color temperature measurements.
*A graphics board and software that support 10-bit output are also necessary for 10-bit display. Equipment that supports DeepColor is required for 10-bit display when connected via the HDMI port.
Connectivity to Keep Your Creativity Flowing
Single Cable Connection with USB Type-C
With USB Type-C, a single cable transmits video signal, USB data, and up to 70 W of power delivery, so you can connect, charge, and create without juggling cords or adapters. This is especially helpful for creators who move between setups or work on laptops in mobile or hybrid environments. The monitor also has DisplayPort and HDMI inputs, and four USB Type-A ports for connecting peripherals.
Sync Signal
The Sync Signal function automatically adjusts brightness, gamma, and color gamut according to the input signal’s metadata. This helps maintain accurate viewing conditions when switching between SDR and HDR or moving across color spaces, reducing manual steps and maintaining consistency from the start of each project. The CS3200X is the first CS Series model to offer Sync Signal.
Immersive Work Environment
Magnetic Shading Hood Included
The bundled magnetic shading hood makes it easy to work free of glare and environmental distractions, attaching and detaching cleanly without complicated assembly. It is the first hood to be bundled with a CS Series monitor.
Commitment to Quality
5-Year Manufacturer’s Warranty
ColorEdge monitors are backed by a manufacturer’s 5-year warranty that covers all components including the LCD panel.* EIZO manufactures its products at its own factories to allow close control over production quality.
*Usage time is limited to 30,000 hours.
Zero Bright Pixels
EIZO guarantees this product will be free from bright sub-pixels for six months from the purchase date.
Low Environmental Impact Materials and Eco-Conscious Packaging
A portion of the plastic used in the monitor is recycled plastic. The CS3200X is packaged using molded pulp made from recycled cardboard and newspaper, and its cables are wrapped in paper instead of plastic bags.
Specifications
| Model | CS3200X-BK |
| Panel | IPS, wide-gamut LED backlight, 31.5″ (80.0 cm) |
| Native resolution | 3840 x 2160 (4K UHD, 16:9) |
| Viewable image size | 697.3 x 392.2 mm |
| Pixel pitch / density | 0.182 x 0.182 mm / 140 ppi |
| Display colors | 1.07 billion colors, 10-bit display (from a palette of 278 trillion, 16-bit LUT) |
| Viewing angles (H / V, typical) | 178° / 178° |
| Brightness (typical) | 350 cd/m2 |
| Contrast ratio (typical) | 1300:1 |
| Response time (typical) | 14 ms (gray-to-gray) |
| Color gamut (typical) | Adobe RGB 99%, DCI-P3 96% |
| HDR gamma | HLG, PQ curve |
| Input terminals | USB Type-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 1.4/2.3) |
| Scanning frequency (H / V) | USB Type-C, DisplayPort: 25–137 kHz / 23–61 Hz; HDMI: 15–135 kHz / 23–61 Hz |
| USB upstream | USB 5Gbps Type-C (DisplayPort Alt Mode, Power Delivery source 70 W max.), USB 5Gbps Type-B |
| USB downstream | USB 5Gbps Type-A x 2, USB 2.0 Type-A x 2 |
| Power input | AC 100–240 V, 50/60 Hz |
| Power consumption | Typical 25 W; maximum 166 W; standby 0.5 W or less |
| Built-in calibration sensor | No (optional external sensor; EX5 listed as an EIZO accessory) |
| Digital Uniformity Equalizer | Yes |
| Preset modes | User, Adobe RGB, sRGB, BT.709, Display P3, DCI-P3, PQ_DCI-P3, HLG_BT.2100, CAL, SYNC_SIGNAL |
| Dimensions (landscape, W x H x D) | 712.7 x 431.5–573.3 x 245 mm; without stand 712.7 x 420.5 x 69.3 mm; with hood 722.7 x 436.5–578.3 x 353.3 mm |
| Net weight | 10.6 kg; without stand 7.7 kg; with hood 11.3 kg |
| Stand | Height adjustment 141.8 mm; tilt 35° up / 5° down; swivel 344° |
| VESA mounting | 100 x 100 mm |
| Operating environment | 0–35°C; humidity 20–80% (non-condensing) |
| Certifications and standards | CB, CE, UKCA, cTUVus, FCC-B, CAN ICES (B), VCCI-B, RCM, RoHS, WEEE (per EIZO; contact EIZO for latest) |
| Software | ColorNavigator 7 and Quick Color Match supported |
| Supplied accessories | USB Type-C cable (2 m), HDMI cable (2 m), AC power cord, USB Type-A to Type-B cable (2 m), setup guide, Factory Report, monitor hood (may vary by country) |
| Warranty | 5 years (30,000 hours), including the LCD panel; zero bright sub-pixels for six months from purchase |
View the CS3200X on EIZO’s website • Dimension drawing (PDF)
Questions about the CS3200X, calibration options, or timing? Call Digital Technology Group at 813.889.0660.
The Eizo ColorEdge CS3200X is a 31.5-inch 4K UHD (3840 x 2160) color management monitor with an IPS wide-gamut panel covering 99% Adobe RGB and 96% DCI-P3, HLG and PQ HDR gamma, USB Type-C with up to 70 W power delivery, a three-sided frameless design, and a magnetic shading hood included. ColorNavigator 7 supported; this bundle adds the EIZO EX5 calibration sensor. Call DTG at 800.681.0024 to confirm availability.
EIZO ColorEdge CS3200X EX5 sensor bundle FAQ
What is the EIZO ColorEdge CS3200X EX5 sensor bundle?
The EIZO ColorEdge CS3200X EX5 sensor bundle (DTG part number CS3200X-BK-CNX) is a 31.5-inch 3840 x 2160 (16:9) color management monitor with Adobe RGB 99% and DCI-P3 96% coverage (EIZO, typical), hardware calibration with the included EIZO EX5 calibration sensor and USB-C with up to 70 W power delivery.
Does the EIZO ColorEdge CS3200X EX5 sensor bundle include a calibration sensor?
Yes. The monitor has no built-in sensor, so this DTG bundle adds the EIZO EX5 calibration sensor for hardware calibration with EIZO ColorNavigator 7.
What color gamut does the EIZO ColorEdge CS3200X EX5 sensor bundle cover?
EIZO lists Adobe RGB 99%, DCI-P3 96% (typical). Display colors: 1.07 billion colors, 10-bit display (from a palette of 278 trillion, 16-bit LUT).
Does the EIZO ColorEdge CS3200X EX5 sensor bundle support HDR?
Yes. EIZO lists HDR gamma support for HLG and the PQ curve. Preset modes: User, Adobe RGB, sRGB, BT.709, Display P3, DCI-P3, PQ_DCI-P3, HLG_BT.2100, CAL, SYNC_SIGNAL.
What inputs does the EIZO ColorEdge CS3200X EX5 sensor bundle have?
EIZO lists these video inputs: USB Type-C, DisplayPort, HDMI. The USB-C port supplies up to 70 W of power to a connected laptop. USB downstream: USB 5Gbps: Type-A x 2, USB 2.0: Type-A x 2.
Is a light-shielding hood included with the EIZO ColorEdge CS3200X EX5 sensor bundle?
Yes. EIZO lists a monitor hood in the supplied accessories.
How bright is the EIZO ColorEdge CS3200X EX5 sensor bundle?
EIZO lists 350 cd/m² brightness, 1300:1 contrast and 14 ms (gray-to-gray) response time (typical values).
How big and heavy is the EIZO ColorEdge CS3200X EX5 sensor bundle?
EIZO lists 712.7 x 431.5 – 573.3 x 245 mm (W x H x D, landscape, with stand) and a net weight of 10.6 kg (about 23.4 lb) with the stand. Height adjustment range: 141.8 mm.
What warranty comes with the EIZO ColorEdge CS3200X EX5 sensor bundle?
EIZO lists a 5-year manufacturer's warranty for ColorEdge monitors (usage time limited to 30,000 hours) and zero bright sub-pixels for six months from the date of purchase.
Where can I buy the EIZO ColorEdge CS3200X EX5 sensor bundle?
Order it from DTG (Digital Technology Group) online or call a DTG specialist toll-free at 800.681.0024. Tech support on DTG's toll-free line is free.
Specifications from EIZO's EIZO ColorEdge CS3200X product page (checked October 8, 2026). Specifications are subject to change by EIZO. Questions? Call DTG toll-free at 800.681.0024 or contact us online.
Eizo ColorEdge CS3200X Dimension Drawing
