Avery PC500-190 Permanent Gloss Black Adhesive Vinyl – 36in x 50yd

$134.00

Add to Wishlist
Add to Wishlist
SKU: 4090OP

Description

Avery Dennison’s North America PC 500 Opaque Permanent Kraft product data sheet (Revision 4, dated 11/30/15) describes PC 500 Promotional Calendered Opaque as “an intermediate flexible, high gloss calendared vinyl designed for use on computer sign cutting equipment” that “provides an attractive appearance and easy cutting, weeding and transferring characteristics for promotional signage applications.”

The color chart on that sheet lists PC500-190-O Black Perm KR, item number 4090O, with 4 years of Zone 1 vertical durability. Face: 3.2 mil (81 microns) high-gloss calendered film. Adhesive: permanent clear acrylic. Liner: 78# bleached kraft. Application surfaces: flat, simple curves.

Features listed: medium durability and outdoor performance; dimensionally stable liner for easy converting; high gloss finish; excellent conversion on CAD plotters; easy cutting and weeding; good dimensional stability; good UV, temperature, humidity, and salt-spray resistance. Conversion methods listed: thermal die-cutting; flat-bed sign-cut; drum-roller sign-cut; steel-rule die-cutting; thermal transfer. Common applications listed: trucks; trailers; cars and vans; banners; architectural signage; directional signage; trains and light rail; buses; outdoor advertising.

Color listed on PDS PC500-190-O Black Perm KR (item # 4090O)
Face 3.2 mil (81 µm) high-gloss calendered film
Adhesive Permanent clear acrylic; 1.0 mil (25 µm)
Liner 78# bleached kraft
Dimensional stability <0.04" (1.016 mm)
Elongation 100% min.
Gloss 90% ± 10
Adhesion, 15 min 3.0 lbs/in (525 N/m)
Adhesion, 24 hr 3.5 lbs/in
Flammability Self extinguishing
Zone 1 vertical durability (PC500-190-O) 4 years
Min. application temperature 50°F (10°C)
Service temperature -50° to 180°F
Shelf life 2 years from date of manufacture at 68°–77°F (20°–25°C) and 50±5% RH
Chemical resistance Resistant to most mild acids, alkalis, and salt solutions
This listing’s roll description 36" × 50 yards (catalog)

Related products

Source: Avery Dennison PC 500 Opaque Permanent Kraft PDS, Rev. 4, 11/30/15.
